Panter FD2H driving unit with SF70 Snow blower
Panter FD2H driving unit with SF70 Snow blowerPanter FD2H driving unit with SF70 Snow blower

Panter FD2H driving unit with SF70 Snow blower

modular self-propelled snow blower with hydrostatic gearbox and single slide control of speed forward and backward; B&S engine 850 I/C with capacity 190 cc; max. output 6.5 HP; iron cylinder sleeve; oil pump and filter; operating width 69 cm
More information
Order No.:01235.019 + 01235.071
Max. output: 1,650 m2/hour
Max. operating width: 69 cm
Engine: Briggs&Stratton 6.5 HP
Travel: yes, single slide control speed forward and backward
The snow blower in connection with Panter FD2H driving unit meets the customer´s requirements on top equipped machine. There is a cylinder with cast iron sleeve, oil pump and oil filter which are the parts of Briggs&Stratton I/C engine. The professional machine needs a professional gearbox which is the TuffTorq K46 DE for sure. It commonly drives the two hundred kilograms weigh lawn tractors carrying the operator on top of that. The axle has a differntial with locking.

DAKR brand means Czech design and production
Our machines are multipurposed which meands that you can attached 15 working adaptors to one driving unit. The SF70 snow blower in connection with Panter FD2H driving unit is intended for regular maintenance not only around the houses, cottages, company´s estates but also for municipalities.
There is a wide range of working adaptors. To the Panter FD2H driving unit it is possible to connect the seat and the adaptors such as mower, mulcher, haymaker, cart, sweeping brush, blade, rotavator, branch crusher etc.

The blade´s transmisson
There is a possibility to set 2 different revolutions of the blade´s speed. When you need to clean fresh powder snow set the faster revolutions (1,850 RPM) to the snow blows as far as possible. While you set the slower revolutions (1,285 RPM) you can remove the heavy wet snow more effectively. Thanks to rotating chimney it is possible to influence the thrown snow direction (forward, aside).

Also the backward gear will help in demanding conditions.
The total weight of the Panter FD2H driving unit with the snow blower is 100 kg. The differential locking allows to keep straight direction. For the winter maintenance there are also the snow chains (order No. 10100.081) available.

Panter FD2H and SF70 snow blower specifications:
Max. output:1,650 m2/hour
Max. operating width:69 cm
Engine:4-stroke Briggs&Stratton 850 I/C
Gearbox:hydrostatic TuffTorq K46 DE
Travel:single slide control speed forward and backward (forward 0÷6 km/hour, backward 0÷3 km/hour)
Axletree:lockable differential and brake
Cylinder:cast iron sleeve
Engine working speed:3,060 rpm
Total max. engine output:6.5 HP / 4.8 kW
Engine output at 3,060 rpm:5.0 HP / 3.7 kW
Torque at 3,060 rpm:11.5 Nm
Engine lubricaton:pressure oil filtration, spray lubrication
Engine vibration attenuation:4 silent blocks
Engine starting:manual
Fuel:gasoline Natural 95
Weight:100 kg
Blade speed:at choice 1,285/1,850 rpm
Feed worm speed:516 rpm
Handlebars:height and side adjustable
Wheels:big blown wheels 4.80/4.00-8" (diameter 420 mm) with V-shaped tread pattern, outer profile at choice 650 or 680 mm
